Description
Grind CamCams work well with fuel injection or carburettor models
Run best with low restriction exhausts (1700-5200 rpm)
Works well with carbs or fuel injection
Bolt-in cam for more torque with stock compression
Can be used with stock valve springs and tappets
Similar to the EV-23 cam
All Andrews gear-driven cams require four-gear set for installation (DS-199532 for 99-06 applications; 0925-0166 or 0925-0152 for 07-17 Twin Cam and 06 Dyna applications).
Installer must check coil bind, valve-to-valve clearance and valve-to-piston clearance.
59G, 60G and 64G cams are for highly tuned engines and require the knowledge of an expert engine builder for proper setup and installation.Cams for maximum torque and horsepower at higher RPM ranges (2600-6000+ RPM) Designed for engines with 9.5:1 compression ratio or higher with 88"-95" Coil bind must be checked, but stock tappets can be used
Details
Exhaust Lift at TDC : 0,181"Intake Duration : 248°
Intake Lift Imperial : 0.550"
Product Name : Cam Kit
Type : Chain
Exhaust Close Imperial : 20°
Intake Duration Imperial : 248°
Exhaust Duration Imperial : 252°
Exhaust Lobe Centreline : 106°
Intake Lift at TDC : 0,197"
Intake Lift at TDC Imperial : 0.197"
Intake Open : 22°
Intake Open Imperial : 22°
Intake Lobe Centreline Imperial : 102°
Exhaust Close : 20°
Exhaust Open : 52°
Application : Exhaust| Intake
Intake Close Imperial : 46°
Intake Lift : 0,550"
Intake Close : 46°
Exhaust Duration : 252°
Intake Lobe Centreline : 102°
Exhaust Lobe Centreline Imperial : 106°
Units : Pair
Exhaust Lift Imperial : 0.550"
Grind : 55 Series| TW55
Exhaust Lift : 0,550"
Exhaust Lift at TDC Imperial : 0.181"
Exhaust Open Imperial : 52°
Fitment
Harley-Davidson FLHR 1450 Road King - 2008, 2009, 2010, 2011, 9891Harley-Davidson FLHR 1450 Road King - 2008, 2009, 2010, 2011, 9892
Harley-Davidson FLHRCI 1450 EFI Road King Classic - 2008, 2009, 2010, 2011, 9893
Harley-Davidson FLHRCI 1450 EFI Road King Classic - 2008, 2009, 2010, 2011, 9894
Harley-Davidson FLHRI 1450 EFI Road King - 2008, 2009, 2010, 2011, 9895
Harley-Davidson FLHRSEI 1550 Road King Screamin Eagle - 2008, 2009, 2010, 2011, 9896
Harley-Davidson FLHRSEI2 1690 Road King Screamin Eagle - 2008, 2009, 2010, 2011, 9897
Harley-Davidson FLHRSI 1450 EFI Road King Custom - 2008, 2009, 2010, 2011, 9898
Harley-Davidson FLHT 1450 Electra Glide - 2008, 2009, 2010, 2011, 9899
Harley-Davidson FLHT 1450 Electra Glide - 2008, 2009, 2010, 2011, 9900
Harley-Davidson FLHTC 1450 Electra Glide Classic - 2008, 2009, 2010, 2011, 9901
Harley-Davidson FLHTCI 1450 EFI Electra Glide Classic - 2008, 2009, 2010, 2011, 9902
Harley-Davidson FLHTCSE2 1690 EFI Electra Glide Screamin Eagle - 2008, 2009, 2010, 2011, 9903
Harley-Davidson FLHTCUI 1450 EFI Electra Glide Ultra Classic - 2008, 2009, 2010, 2011, 9904
Harley-Davidson FLHTCUI 1450 EFI Electra Glide Ultra Classic - 2008, 2009, 2010, 2011, 9905
Harley-Davidson FLHTCUSE 1690 Electra Glide Ultra Classic Screamin Eagle - 2008, 2009, 2010, 2011, 9906
Harley-Davidson FLHTI 1450 EFI Electra Glide - 2008, 2009, 2010, 2011, 9907
Harley-Davidson FLHXI 1450 EFI Street Glide - 2008, 2009, 2010, 2011, 9908
Harley-Davidson FLSTC 1450 Heritage Softail Classic - 2008, 2009, 2010, 2011, 9909
Harley-Davidson FLSTCI 1450 EFI Heritage Softail Classic - 2008, 2009, 2010, 2011, 9910
Harley-Davidson FLSTF 1450 Fat Boy - 2008, 2009, 2010, 2011, 9911
Harley-Davidson FLSTFI 1450 EFI Fat Boy - 2008, 2009, 2010, 2011, 9912
Harley-Davidson FLSTFI 1550 EFI Fat Boy 15th Anniversary - 2008, 2009, 2010, 2011, 9913
Harley-Davidson FLSTFSE 1690 Fat Boy Screamin Eagle - 2008, 2009, 2010, 2011, 9914
Harley-Davidson FLSTFSE2 1690 Fat Boy Screamin Eagle - 2008, 2009, 2010, 2011, 9915
Harley-Davidson FLSTI 1450 EFI Heritage Softail - 2008, 2009, 2010, 2011, 9916
Harley-Davidson FLSTNI 1450 EFI Softail Deluxe - 2008, 2009, 2010, 2011, 9917
Harley-Davidson FLSTS 1450 Heritage Softail Springer - 2008, 2009, 2010, 2011, 9918
Harley-Davidson FLSTSC 1450 Softail Springer Classic - 2008, 2009, 2010, 2011, 9919
Harley-Davidson FLSTSCI 1450 EFI Softail Springer Classic - 2008, 2009, 2010, 2011, 9920
Harley-Davidson FLTRSEI 1550 Road Glide Screamin Eagle - 2008, 2009, 2010, 2011, 9921
Harley-Davidson FXD 1450 Dyna Super Glide - 2008, 2009, 2010, 2011, 9922
Harley-Davidson FXD 1450 Dyna Super Glide - 2008, 2009, 2010, 2011, 9923
Harley-Davidson FXDCI 1450 EFI Dyna Super Glide Custom - 2008, 2009, 2010, 2011, 9924
Harley-Davidson FXDI 1450 EFI Dyna Super Glide - 2008, 2009, 2010, 2011, 9925
Harley-Davidson FXDL 1450 Dyna Low Rider - 2008, 2009, 2010, 2011, 9926
Harley-Davidson FXDL 1450 Dyna Low Rider - 2008, 2009, 2010, 2011, 9927
Harley-Davidson FXDLI 1450 EFI Dyna Low Rider - 2008, 2009, 2010, 2011, 9928
Harley-Davidson FXDWG 1450 Dyna Wide Glide - 2008, 2009, 2010, 2011, 9929
Harley-Davidson FXDWG 1450 Dyna Wide Glide - 2008, 2009, 2010, 2011, 9930
Harley-Davidson FXDWG2 1450 Dyna Wide Glide Limited Edition - 2008, 2009, 2010, 2011, 9931
Harley-Davidson FXDWG3 1450 Dyna Wide Glide Limited Edition - 2008, 2009, 2010, 2011, 9932
Harley-Davidson FXDWGI 1450 EFI Dyna Wide Glide - 2008, 2009, 2010, 2011, 9933
Harley-Davidson FXDX 1450 Dyna Super Glide Sport - 2008, 2009, 2010, 2011, 9934
Harley-Davidson FXDXI 1450 EFI Dyna Super Glide Sport - 2008, 2009, 2010, 2011, 9935
Harley-Davidson FXDXT 1450 Dyna Super Glide T-Sport - 2008, 2009, 2010, 2011, 9936
Harley-Davidson FXST 1450 Softail - 2008, 2009, 2010, 2011, 9937
Harley-Davidson FXSTB 1450 Softail Night Train - 2008, 2009, 2010, 2011, 9938
Harley-Davidson FXSTBI 1450 EFI Softail Night Train - 2008, 2009, 2010, 2011, 9939
Harley-Davidson FXSTD 1450 Softail Deuce - 2008, 2009, 2010, 2011, 9940
Harley-Davidson FXSTDI 1450 EFI Softail Deuce - 2008, 2009, 2010, 2011, 9941
Harley-Davidson FXSTI 1450 EFI Softail - 2008, 2009, 2010, 2011, 9942
Harley-Davidson FXSTS 1450 Softail Springer - 2008, 2009, 2010, 2011, 9943
Harley-Davidson FXSTSI 1450 EFI Softail Springer - 2008, 2009, 2010, 2011, 9944
