Description
Grind CamCams work well with fuel injection or carburettor models
Run best with low restriction exhausts (1700-5200 rpm)
Works well with carbs or fuel injection
Bolt-in cam for more torque with stock compression
Can be used with stock valve springs and tappets
Similar to the EV-23 cam
All Andrews gear-driven cams require four-gear set for installation (DS-199532 for 99-06 applications; 0925-0166 or 0925-0152 for 07-17 Twin Cam and 06 Dyna applications).
Installer must check coil bind, valve-to-valve clearance and valve-to-piston clearance.
59G, 60G and 64G cams are for highly tuned engines and require the knowledge of an expert engine builder for proper setup and installation.Designed for 95"+ motors with major head work Maximum torque and HP at middle and upper RPM ranges (2700-6500+ RPM) Coil bind and valve-to-valve and valve-to-piston clearance must be checked
Details
Exhaust Close Imperial : 22°Intake Lift at TDC Imperial : 0.205"
Application : Exhaust| Intake
Intake Lift at TDC : 0,205"
Intake Open Imperial : 24°
Exhaust Close : 22°
Intake Open : 24°
Intake Close : 56°
Exhaust Lift : 0,560"
Exhaust Lift at TDC Imperial : 0.192"
Intake Duration : 260°
Intake Lobe Centreline Imperial : 106°
Exhaust Lobe Centreline Imperial : 108°
Exhaust Duration Imperial : 260°
Exhaust Lift Imperial : 0.560"
Exhaust Open Imperial : 58°
Exhaust Open : 58°
Exhaust Duration : 260°
Intake Close Imperial : 56°
Intake Lift : 0,560"
Type : Chain
Product Name : Cam Kit
Intake Lift Imperial : 0.560"
Exhaust Lobe Centreline : 108°
Units : Pair
Exhaust Lift at TDC : 0,192"
Intake Duration Imperial : 260°
Intake Lobe Centreline : 106°
Grind : 60 Series
Fitment
Harley-Davidson FLHR 1450 Road King - 2008, 2009, 2010, 2011, 10107Harley-Davidson FLHR 1450 Road King - 2008, 2009, 2010, 2011, 10108
Harley-Davidson FLHRCI 1450 EFI Road King Classic - 2008, 2009, 2010, 2011, 10109
Harley-Davidson FLHRCI 1450 EFI Road King Classic - 2008, 2009, 2010, 2011, 10110
Harley-Davidson FLHRI 1450 EFI Road King - 2008, 2009, 2010, 2011, 10111
Harley-Davidson FLHRSEI 1550 Road King Screamin Eagle - 2008, 2009, 2010, 2011, 10112
Harley-Davidson FLHRSEI2 1690 Road King Screamin Eagle - 2008, 2009, 2010, 2011, 10113
Harley-Davidson FLHRSI 1450 EFI Road King Custom - 2008, 2009, 2010, 2011, 10114
Harley-Davidson FLHT 1450 Electra Glide - 2008, 2009, 2010, 2011, 10115
Harley-Davidson FLHT 1450 Electra Glide - 2008, 2009, 2010, 2011, 10116
Harley-Davidson FLHTC 1450 Electra Glide Classic - 2008, 2009, 2010, 2011, 10117
Harley-Davidson FLHTCI 1450 EFI Electra Glide Classic - 2008, 2009, 2010, 2011, 10118
Harley-Davidson FLHTCSE2 1690 EFI Electra Glide Screamin Eagle - 2008, 2009, 2010, 2011, 10119
Harley-Davidson FLHTCUI 1450 EFI Electra Glide Ultra Classic - 2008, 2009, 2010, 2011, 10120
Harley-Davidson FLHTCUI 1450 EFI Electra Glide Ultra Classic - 2008, 2009, 2010, 2011, 10121
Harley-Davidson FLHTCUSE 1690 Electra Glide Ultra Classic Screamin Eagle - 2008, 2009, 2010, 2011, 10122
Harley-Davidson FLHTI 1450 EFI Electra Glide - 2008, 2009, 2010, 2011, 10123
Harley-Davidson FLHXI 1450 EFI Street Glide - 2008, 2009, 2010, 2011, 10124
Harley-Davidson FLSTC 1450 Heritage Softail Classic - 2008, 2009, 2010, 2011, 10125
Harley-Davidson FLSTCI 1450 EFI Heritage Softail Classic - 2008, 2009, 2010, 2011, 10126
Harley-Davidson FLSTF 1450 Fat Boy - 2008, 2009, 2010, 2011, 10127
Harley-Davidson FLSTFI 1450 EFI Fat Boy - 2008, 2009, 2010, 2011, 10128
Harley-Davidson FLSTFI 1550 EFI Fat Boy 15th Anniversary - 2008, 2009, 2010, 2011, 10129
Harley-Davidson FLSTFSE 1690 Fat Boy Screamin Eagle - 2008, 2009, 2010, 2011, 10130
Harley-Davidson FLSTFSE2 1690 Fat Boy Screamin Eagle - 2008, 2009, 2010, 2011, 10131
Harley-Davidson FLSTI 1450 EFI Heritage Softail - 2008, 2009, 2010, 2011, 10132
Harley-Davidson FLSTNI 1450 EFI Softail Deluxe - 2008, 2009, 2010, 2011, 10133
Harley-Davidson FLSTS 1450 Heritage Softail Springer - 2008, 2009, 2010, 2011, 10134
Harley-Davidson FLSTSC 1450 Softail Springer Classic - 2008, 2009, 2010, 2011, 10135
Harley-Davidson FLSTSCI 1450 EFI Softail Springer Classic - 2008, 2009, 2010, 2011, 10136
Harley-Davidson FLTRSEI 1550 Road Glide Screamin Eagle - 2008, 2009, 2010, 2011, 10137
Harley-Davidson FXD 1450 Dyna Super Glide - 2008, 2009, 2010, 2011, 10138
Harley-Davidson FXD 1450 Dyna Super Glide - 2008, 2009, 2010, 2011, 10139
Harley-Davidson FXDCI 1450 EFI Dyna Super Glide Custom - 2008, 2009, 2010, 2011, 10140
Harley-Davidson FXDI 1450 EFI Dyna Super Glide - 2008, 2009, 2010, 2011, 10141
Harley-Davidson FXDL 1450 Dyna Low Rider - 2008, 2009, 2010, 2011, 10142
Harley-Davidson FXDL 1450 Dyna Low Rider - 2008, 2009, 2010, 2011, 10143
Harley-Davidson FXDLI 1450 EFI Dyna Low Rider - 2008, 2009, 2010, 2011, 10144
Harley-Davidson FXDWG 1450 Dyna Wide Glide - 2008, 2009, 2010, 2011, 10145
Harley-Davidson FXDWG 1450 Dyna Wide Glide - 2008, 2009, 2010, 2011, 10146
Harley-Davidson FXDWG2 1450 Dyna Wide Glide Limited Edition - 2008, 2009, 2010, 2011, 10147
Harley-Davidson FXDWG3 1450 Dyna Wide Glide Limited Edition - 2008, 2009, 2010, 2011, 10148
Harley-Davidson FXDWGI 1450 EFI Dyna Wide Glide - 2008, 2009, 2010, 2011, 10149
Harley-Davidson FXDX 1450 Dyna Super Glide Sport - 2008, 2009, 2010, 2011, 10150
Harley-Davidson FXDXI 1450 EFI Dyna Super Glide Sport - 2008, 2009, 2010, 2011, 10151
Harley-Davidson FXDXT 1450 Dyna Super Glide T-Sport - 2008, 2009, 2010, 2011, 10152
Harley-Davidson FXST 1450 Softail - 2008, 2009, 2010, 2011, 10153
Harley-Davidson FXSTB 1450 Softail Night Train - 2008, 2009, 2010, 2011, 10154
Harley-Davidson FXSTBI 1450 EFI Softail Night Train - 2008, 2009, 2010, 2011, 10155
Harley-Davidson FXSTD 1450 Softail Deuce - 2008, 2009, 2010, 2011, 10156
Harley-Davidson FXSTDI 1450 EFI Softail Deuce - 2008, 2009, 2010, 2011, 10157
Harley-Davidson FXSTI 1450 EFI Softail - 2008, 2009, 2010, 2011, 10158
Harley-Davidson FXSTS 1450 Softail Springer - 2008, 2009, 2010, 2011, 10159
Harley-Davidson FXSTSI 1450 EFI Softail Springer - 2008, 2009, 2010, 2011, 10160
